MAX1561ETA MAX1561 LED Lighting Drivers
| Part number | Brand | Date | QTY | Package | Remarks |
| MAX1561ETA | MAXIM | 14+ROHS | 7500 | QFN |
Original have in stock |
PDF Datasheet：
Specification：
| Packaging | Tape & Reel (TR) |
|---|---|
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | Yes |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 2.6V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | 26V |
| Current - Output / Channel | 950mA (Switch) |
| Frequency | 1MHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-WDFN Exposed Pad |
| Supplier Device Package | 8-TDFN-EP (3x3) |
Picture：
MJD is a corporation which engaged in agency electronic components. MJD Through seventeen years unrimitting efforts, aspire to provide our customers with world-leading products and service. Nowalready became a one of the most famous electronic components distributor in China.
