AK8858 PS/SD Multi Format Video Decoder

AK8858 AK8858VQ PS/SD Multi Format Video Decoder

PDF Datasheet：

Feature：

■ Decodes composite and S-Video signals NTSC/ PAL-B, D, G, H, I, N, Nc, M, 60 /SECAM

■ Decode 525i / 625i YPbPr component video signals

■ Decode 525p / 625p YPbPr component video signals

■ 10 input channel

■ 10-bit 54MHz ADC 2 channel

■ Internally built PLL

■ Internal analog bandwidth filter

■ Programmable Gain Amp (PGA) (-3.25dB～10dB)

■ Adaptive automatic Gain Control (AGC)

■ Auto Color Control (Composite and S-Video signals)

■ Image adjustment (Contrast, Brightness, Saturation, HUE, Sharpness)

■ Automatic input signal detection (NTSC/ PAL/ SECAM detect、Interlace/ Progressive detect)

■ Adaptive 2-D Y/C separation

■ Output data format

YCbCr 4:2:2 or RGB 8:8:8

■ Output interface

(YCbCr)

Interlace: ITU-R BT.656 (8bit 27MHz) and 16bit 13.5MHz with EAV/ SAV

Progressive: 16bit 27MHz and 8bit 54MHz with EAV/ SAV

(RGB)

Interlace: 8bit:8bit:8bit 13.5MHz with EAV/ SAV

Progressive: 8bit:8bit:8bit 27MHz with EAV/ SAV

*EAV/ SAV output can be disabled via register

■ HD, VD, DVALID and FIELD (VD, DVALID, FIELD can be select up to 2 output via register setting)

■ Closed Caption / WSS / CGMS-A signal decoding (output via register).

■ Macrovision signal detection (Rovi certification)

■ I2C control

■ Powerdown function

■ Internal VREF

■ Core supply voltage: 1.70∼2.00V

■ I/O power supply: 1.70∼3.60V

■ Operating temperature: −40°C∼105°C

■ 80-pin LQFP package (12.0mm x 12.0mm)
