SNJ54LVCH244AJ SNJ54LVCH244A octal buffer/line driver

SNJ54LVCH244AJ SNJ54LVCH244A octal buffer/line driver

Features：

 Operate From 1.65 V to 3.6 V • I

off Supports Partial-Power-Down Mode

Inputs Accept Voltages to 5.5 V Operation

Max t • Bus Hold on Data Inputs Eliminates the Need

pd of 5.9 ns at 3.3 V

for External Pullup/Pulldown Resistors

Typical VOLP (Output Ground Bounce)

<0.8 V at V • Latch-Up Performance Exceeds 250 mA Per

CC = 3.3 V, TA = 25°C

JESD 17

Typical VOHV (Output VOH Undershoot)

>2 V at V • ESD Protection Exceeds JESD 22

CC = 3.3 V, TA = 25°C

– 2000-V Human-Body Model (A114-A)

Support Mixed-Mode Signal Operation on All

Ports – 200-V Machine Model (A115-A)

(5-V Input/Output Voltage With 3.3-V VCC) – 1000-V Charged-Device Model (C101)
