CSD25402Q3A MOSFET P-CH Pwr MOSFET

Order details

Please contact us to get the newest prices

Part number

CSD25402Q3A

Product catalog

MOSFET P-CH Pwr MOSFET

Brand

TI

Application

DC-DC Converters

Feature

Manufacturer: Texas Instruments

Product Category: MOSFET

RoHS: RoHS Compliant Details

Id - Continuous Drain Current: - 15 A

Vds - Drain-Source Breakdown Voltage: - 20 V

Rds On - Drain-Source Resistance: 8.9 mOhms

Transistor Polarity: P-Channel

Vgs - Gate-Source Breakdown Voltage: - 12 V

Vgs th - Gate-Source Threshold Voltage: - 900 mV

Qg - Gate Charge: 7.5 nC

Maximum Operating Temperature: + 125 C

Pd - Power Dissipation: 2.8 W

Mounting Style: SMD/SMT

Package / Case: VSON-FET-8

Packaging: Reel

Brand: Texas Instruments

Channel Mode: Depletion

Ciss - Input Capacitance: 1790 pF

Configuration: Single Channel

Fall Time: 12 ns

Forward Transconductance - Min: 59 S

Minimum Operating Temperature: - 55 C

Rise Time: 7 ns

Series: CSD25402Q3A

Factory Pack Quantity: 2500

Tradename: NexFET

Typical Turn-Off Delay Time: 25 ns

Data sheet ：
