AD AD8346 AD8346ARUZ Quadrature Modulator

Order details

Please contact us to get the newest prices

Part number

AD8346ARUZ

Family

Quadrature Modulator

Brand

AD

Application

Digital and spread spectrum communication systems

Feature

High accuracy

1 degree rms quadrature error @ 1.9 GHz

0.2 dB I/Q amplitude balance @ 1.9 GHz

Broad frequency range: 0.8 GHz to 2.5 GHz

Sideband suppression: −46 dBc @ 0.8 GHz

Sideband suppression: −36 dBc @ 1.9 GHz

Modulation bandwidth: dc to 70 MHz

0 dBm output compression level @ 0.8 GHz

Noise floor: −147 dBm/Hz

Single 2.7 V to 5.5 V supply

Quiescent operating current: 45 mA

Standby current: 1 μA

16-lead TSSOP

APPLICATIONS

Digital and spread spectrum communication systems

Cellular/PCS/ISM transceivers

Wireless LAN/wireless local loop

QPSK/GMSK/QAM modulators

Single-sideband (SSB) modulators

Frequency synthesizers

Image reject mixer

Data sheet

Payment methods

1.T/T wire transfer   2.Paypal   3.Western union  4.Cash

Transport way

1.   EMS

2.   TNT

3.   DHL

4.   FedEx

5.   China post

6.   Other special

Warranty

All parts are New And Original enjoy within 45 days return .
