LINEAR LTC6101 LTC6101HVBCS5 Current Sense Amplifier

LINEAR

LTC6101HVBCS5

LTC6101HVBCS5 date sheet

Product category

High Voltage Current Sense Amplifier

Application

Current Shunt Measurement

Specification

Supply Range:

5V to 100V, 105V Absolute Maximum (LTC6101HV)

4V to 60V, 70V Absolute Maximum (LTC6101)

Low Offset Voltage: 300μV Max

Fast Response: 1μs Response Time (0V to 2.5V on

a 5V Output Step)

GaiConfi gurable with 2 Resistors

Low Input Bias Current: 170nA Max

PSRR: 118dB Min

Output Current: 1mA Max

Low Supply Current: 250μA, V S = 12V

Specifi ed Temperature Range: –40°C to 125°C

Operating Temperature Range: –55°C to 125°C

Low Profi le (1mm) SOT-23 (ThinSOT™) Package
