TI TPS2052B TPS2052BDR Power Distribution Switches

TI

TPS2052BDR

TPS2052BDR date sheet

Product category

Current-Limited, Power-Distribution Switches

Application

Heavy Capacitive Loads

Short-Circuit Protections

Specification

70-mΩ High-Side MOSFET

• 500-mA Continuous Current

• Thermal and Short-Circuit Protection

• Accurate Current Limit

(0.75 A min, 1.25 A max)

• Operating Range: 2.7 V to 5.5 V

• 0.6-ms Typical Rise Time

• Undervoltage Lockout

• Deglitched Fault Report (OC)

• No OC Glitch During Power Up

• Maximum Standby Supply Current:

1-μA (Single, Dual) or 2-μA (Triple, Quad)

• Ambient Temperature Range: -40°C to 85°C

• UL Recognized, File Number E169910

• Additional UL Recognition for TPS2042B and

TPS2052B for Ganged Configuration
