ST HDMI2C1-14HD ESD protection and signal conditioning

ST

HDMI2C1-14HD

HDMI2C1-14HD  date sheet

Product category

ESD protection and signal conditioning

Application

HDMI™ 1.4 source interface

Description

HDMI 1.3 and 1.4 compliant: from -40 to 85 °C

8 kV contact ESD protection on connector side

Supports direct connection to low-voltage

HDMI ASIC and/or CEC driver (down to 1.8 V)

High integration level in 1 package

TMDS high bandwidth ESD protection

DDC (I2C) link protection, bi-directional signal

conditioning circuit, and dynamic pull-up

CEC bus protection, bi-directional level-shifter,

backdrive protection, and independent

structure from main power supply

HEAC link protection and line matching

HPD pull down and signal conditioning

Short-circuit protection on 5 V output

Over temperature protection

Proposed in QFN 36 leads 500 µm pitch
