AVAGO ACPM-5004 3x3mm Power Amplifier Module with Coupler

AVAGO

ACPM-5004

ACPM-5004 date sheet

Product category

Multimode PA - UMTS 1700MHz PA (1710-1785MHz)

3x3mm Power Amplifier Module with Coupler

Application

UMTS (WCDMA, HSDPA, HSUPA, HSPA+)

LTE

CDMA

Description

ThinPackage(0.9mmtyp)

ExcellentLinearity

3-modepowercontrolwithVbpandVmode

–Bypass/MidPowerMode/HighPowerMode

HighEfficiencyatmaxoutputpower

10-pinsurfacemountingpackage

Internal50ohmmatchingnetworksforbothRFinput

andoutput

Integratedcoupler

–CouplerandIsolationportsfordaisychain

Lead-free,RoHScompliant,Green
