AIROHA AR8159 Low Noise Amplifier for GPS/GNSS

Description


Key Features

• Support full GNSS L1 band: 1559MHz~1610MHz

• Low noise figure: 0.8 dB

• High gain: 18.5 dB

• High Input P1-dB: -12 dBm.

• High In-band IIP3: -2 dBm

• Support 1.6 ~ 3.6 V supply voltage

• Low supply current: 5.8mA

• Low disable current: 1uA

• Small package: 6-pin uDFN 1.5mm x 1.0mm x 0.75mm

​Application

• GPS Device
