AD AD5933 AD5933YRSZ 1 MSPS, 12-Bit Impedance Converter, Network Analyzer

Description


Features

Programmable output peak-to-peak excitation voltage

to a maximum frequency of 100 kHz

Programmable frequency sweep capability with

serial I2C interface

Frequency resolution of 27 bits (<0.1 Hz)

Impedance measurement range from 1 kΩ to 10 MΩ

Capable of measuring of 100 Ω to 1 kΩ with additional

circuitry

Internal temperature sensor (±2°C)

Internal system clock option

Phase measurement capability

System accuracy of 0.5%

2.7 V to 5.5 V power supply operation

Temperature range: −40°C to +125°C

16-lead SSOP package

Qualified for automotive applications
