MICROSEMI A3P250 VQG100 ProASIC3 Flash Family FPGAs

Description


Features

High Capacity

• 15 k to 1 M System Gates

• Up to 144 kbits of True Dual-Port SRAM

• Up to 300 User I/Os

Reprogrammable Flash Technology

• 130-nm, 7-Layer Metal (6 Copper), Flash-Based CMOS

Process

• Instant On Level 0 Support

• Single-Chip Solution

• Retains Programmed Design when Powered Off

High Performance

• 350 MHz System Performance

• 3.3 V, 66 MHz 64-Bit PCI†

In-System Programming (ISP) and Security

• ISP Using On-Chip 128-Bit Advanced Encryption Standard

(AES) Decryption (except ARM®-enabled ProASIC®3 devices)

via JTAG (IEEE 1532–compliant)†

• FlashLock® to Secure FPGA Contents

Low Power

• Core Voltage for Low Power

• Support for 1.5 V-Only Systems

• Low-Impedance Flash Switches

High-Performance Routing Hierarchy

• Segmented, Hierarchical Routing and Clock Structure
