CURRENT LIMITED POWER DISTRIBUTION SWITCHES |
|
Application |
Notebook, Desktop and Palmtop PCs Monitors, Keyboards, Scanners, and Printers Digital Cameras, Phones, and PBXs Hot-Insertion Applications |
|
Datasheet |
Details
|
Description |
|
Features 135-mΩ -Maximum (5-V Input) High-Side MOSFET Switch 250 mA Continuous Current Short-Circuit and Thermal Protection With Overcurrent Logic Output Operating Range . . . 2.7-V to 5.5-V Logic-Level Enable Input 2.5-ms Typical Rise Time Undervoltage Lockout 10 µA Maximum Standby Supply Current Bidirectional Switch Available in 8-pin SOIC and PDIP Packages Ambient Temperature Range, –40°C to 85°C 2-kV Human-Body-Model, 200-V Machine-Model ESD Protection APPLICATIONS Notebook, Desktop and Palmtop PCs Monitors, Keyboards, Scanners, and Printers Digital Cameras, Phones, and PBXs Hot-Insertion Applications |
| Family |
PMIC - Power Distribution Switches, Load Drivers |
|---|---|
| Series | - |
| Packaging | Tape & Reel (TR) |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 2.7 V ~ 5.5 V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 250mA |
| Rds On (Typ) | 80 mOhm |
| Input Type | Non-Inverting |
| Features | Status Flag |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO |
| Operating Temperature | 0°C ~ 125°C (TJ) |
