Z Wave ZM2102 Integrated Z Wave RF Module

Description


Features

Interfaces

10 General Purpose I/O’s

TwInterrupt Inputs

Serial UART

SPI Interface

Triac Control Interface

PWM Output

Four multiplexed 12/8 bit

ADC inputs

ZW0201 Single Chip

Optimized 8051 CPU Core

32kbyte Flash

2kbyte SRAM

Power-On-Reset / BrownOut

Detection

Supply Voltage: 2.1V-3.6V

Power Consumption

TX@-5dBm = 24mA

TX@0dBm = 36mA

RX = 23mA

Power down/sleep

mode = 2.5μA

RF Freq: 908.42MHz (US) /

868.42MHz (EU)

High Sensitivity (-102/-98dBm)

FSK Modulation 9.6kbps/40kbps Data Rate

-20dBm t0dBm Output

power (ZW0201)

Complies with EN 300 220

and FCC CFR47 part 15

Applications

Home Automation

Lighting/Drape Control

Automated Meter Reading

Access Control

Universal Remote

Controls
