MAXIM MAX15013 MAX15013AASA 175V/2A Half-Bridge MOSFET Driver

Description


Features

HIP2100/HIP2101 Pin Compatible (MAX15012A/C and MAX15013A/C)

Up to 175V Input Operation

8V to 12.6V VDD Input Voltage Range

2A Peak Source and Sink Current Drive Capability

35ns Typical Propagation Delay

Guaranteed 8ns Propagation Delay Matching

Between Drivers

Up to 500kHz Switching Frequency

Available in CMOS (VDD/2) or TTL Logic-Level

Inputs with Hysteresis

Up to 14V Logic Inputs Independent of Input Voltage

Low 2.5pF Input Capacitance

Low 70µA Supply Current

Versions Available with Combination of

Noninverting and Inverting Drivers (MAX15012B/D

and MAX15013B/D)

Available in Industry-Standard 8-Pin SO and

Thermally Enhanced SO Packages
