AD ADN2525 ADN2525ACPZ Laser Diode Driver 10.7GBPS

Description


Features

Up to 10.7 Gbps operation

Very low power: 670 mW (IBIAS = 40 mA, IMOD = 40 mA)

Typical 24 ps rise/fall times

Full back-termination of output transmission lines

Compatible with XMD-MSA TOSA

Drives TOSAs with resistances ranging from 5 Ω to 50 Ω

PECL-/CML-compatible data inputs

Bias current range: 10 mA to 100 mA

Differential modulation current range: 10 mA to 80 mA

Automatic laser shutdown (ALS)

3.3 V operation

Compact 3 mm × 3 mm LFCSP

Voltage input control for bias and modulation currents

XFP-compliant bias current monitor

Optical evaluation board available

Medical Instruments

Test Equipment
