Manufacturer Part |
|
|
Product Category |
Li-Ion Battery Pack Manager |
|
Application |
Notebook/Netbook PCs Medical and Test Equipment Portable Instrumentation |
|
Datasheet |
Details
|
Description |
|
Features Fully Integrated 1-Series, 2-Series, 3-Series, and 4-Series Li-Ion or Li-Polymer Cell Battery Pack Manager and Protection Next-Generation Patented Impedance Track Technology Accurately Measures Available Charge in Li-Ion and Li-Polymer Batteries High Side N-CH Protection FET Drive Integrated Cell Balancing While Charging or At Rest Full Array of Programmable Protection Features Voltage Current Temperature Charge Timeout CHG/DSG FETs AFE |
| Function | Multi-Function Controller |
|---|---|
| Battery Chemistry | Lithium-Ion/Polymer |
| Number of Cells | 1 ~ 4 |
| Fault Protection | Over Current, Over Temperature, Over/Under Voltage, Short Circuit |
| Interface | SMBus |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 32-VFQFN Exposed Pad |
| Supplier Device Package | 32-VQFN (4x4) |
| Drawing Number | 296; 4207560; RSM; 32 |
