TI TXS0102 TXS0102DQER Bidirectional Voltage-Level Translator

Description


Features

No Direction-Control Signal Needed

Max Data Rates

– 24 Mbps (Push Pull)

– 2 Mbps (Open Drain)

Available in the Texas Instruments NanoStar Package

1.65 V to 3.6 V on A port and 2.3 V to 5.5 V on B

port (VCCA ≤ VCCB)

VCC Isolation Feature: If Either VCC Input Is at

GND, Both Ports Are in the High-Impedance State

No Power-Supply Sequencing Required: Either

VCCA or VCCB Can Be Ramped First

Ioff Supports Partial-Power-Down Mode Operation

Latch-Up Performance Exceeds 100 mA Per

JESD 78, Class II

ESD Protection Exceeds JESD 22

– A Port

– 2500-V Human-Body Model (A114-B)

– 250-V Machine Model (A115-A)

– 1500-V Charged-Device Model (C101)

– B Port

– 8-kV Human-Body Model (A114-B)

– 250-V Machine Model (A115-A)

– 1500-V Charged-Device Model (C101)
