XILINX XC2S150-5PQ208C IC FPGA 140 I/O 208PQFP

Features


DS001-3 (v2.8) June 13, 2008

• DC Specifications

- Absolute Maximum Ratings

- Recommended Operating Conditions

- DC Characteristics

- Power-On Requirements

- DC Input and Output Levels

• Switching Characteristics

- Pin-to-Pin Parameters

- IOB Switching Characteristics

- Clock Distribution Characteristics

- DLL Timing Parameters

- CLB Switching Characteristics

- Block RAM Switching Characteristics

- TBUF Switching Characteristics

- JTAG Switching Characteristics

Category

Integrated Circuits (ICs)

Family

Embedded - FPGAs (Field Programmable Gate Array)

Manufacturer

Xilinx-Inc.

Series

Spartan®-II

Number of LABs/CLBs

864

Number of Logic Elements/Cells

3888

Total RAM Bits

49152

Number of I/O

140

Number of Gates

150000

Voltage - Supply

2.375 V ~ 2.625 V

Mounting Type

Surface Mount

Operating Temperature

0°C ~ 85°C (TJ)

Package / Case

208-BFQFP

Supplier Device Package

208-PQFP (28x28)
