Honeywell Microelectronic HMC5983 TR 3-Axis Digital Compass IC

Features


FEATURES

3-Axis Magnetoresistive Sensors and

ASIC in a 3.0x3.0x0.9mm LCC Surface

Mount Package

Temperature Compensated Data Output

and Temperature Output

Automatic Offset Compensation

12-Bit ADC Coupled with Low Noise

AMR Sensors Achieves 2 milli-gauss

Field Resolution

I2C (Standard, Fast, High-Speed modes)

or SPI Digital Interface

Fast 220 Hz Maximum Output Rate

Built-in Self Test

Low Voltage Operations (2.16 to 3.6V)

and Low Power Consumption (100 μA)

Built-In Strap Drive Circuits

Lead Free Package Construction

Wide Magnetic Field Range (+/-8 Oe)

Software and Algorithm Support

Available
