TI INA199B INA199B2DCKR Current Shunt Monitor

Features


Features

Wide Common-Mode Range: –0.3 V to 26 V

Offset Voltage: ±150 μV (Maximum)

(Enables Shunt Drops of 10-mV Full-Scale)

Accuracy

– ±1.5% Gain Error (Maximum Over

Temperature)

– 0.5-μV/°C Offset Drift (Maximum)

– 10-ppm/°C Gain Drift (Maximum)

Choice of Gains:

– INA199x1: 50 V/V

– INA199x2: 100 V/V

– INA199x3: 200 V/V

Quiescent Current: 100 μA (Maximum)

Packages: 6-Pin SC70, 10-Pin UQFN

Applications

Notebook Computers

Cell Phones

Qi-Compliant Wireless Charging Transmitters

Telecom Equipment

Power Management

Battery Chargers
