Molex 52207-0785 FFC FPC Connector SMT

Features


FEATURES

Status   Planned for Obsolescence

Category     FFC/FPC Connectors

Series   52207

Overview    FFC-FPC (SMT)

Product Name    Easy-On

UPC      822348117895

Circuits (Loaded)     7

Color - Resin     Natural

Contact Position Top

Durability (mating cycles max)    30

Entry Angle  90° Angle

Flammability      94V-0

Mated Height     2.70mm

Material - Metal  Phosphor Bronze

Material - Plating Mating  Tin-Bismuth

Material - Plating Termination Tin-Bismuth

Material - Resin  Nylon

Net Weight  341.100/mg

Number of Rows     1

Orientation  Right Angle

PC Tail Length   2.00mm

PCB Locator No

PCB Retention    Yes

Packaging Type Embossed Tape on Reel

Pitch - Mating Interface   1.00mm

Pitch - Termination Interface 1.00mm

Polarized to PCB Yes

Stackable    No

Temperature Range - Operating  -30°C to +85°C

Termination Interface: Style  Surface Mount

Wire/Cable Type      FFC/FPC

Electrical

(Please review the Product Specification for specific details.)

Current - Maximum per Contact   1.0A

Voltage - Maximum  125V
