Winbond W25Q16JV W25Q16JVSSIQ 3V 16M-BIT SERIAL FLASH MEMORY

Features


FEATURES

New Family of SpiFlash Memories

W25Q16JV: 16M-bit / 2M-byte (2,097,152)

Standard SPI: CLK, /CS, DI, DO

Dual SPI: CLK, /CS, IO0, IO1

Quad SPI: CLK, /CS, IO0, IO1, IO2, IO3

Highest Performance Serial Flash

133MHz Single, Dual/Quad SPI clocks

266/532MHz equivalent Dual/Quad SPI

66MB/S continuous data transfer rate

Min. 100K Program-Erase cycles per sector

More than 20-year data retention

Efficient “Continuous Read”

Continuous Read with 8/16/32/64-Byte Wrap

As few as 8 clocks to address memory

Allows true XIP (execute in place) operation

Outperforms X16 Parallel Flash

Low Power, Wide Temperature Range

Single 2.7V to 3.6V supply

-40°C to +85°C operating range

<1µA Power-down (typ.)
