Infineon BGA925L6 Silicon Germanium GNSS Low Noise Amplifier

Features


FEATURES

Insertion power gain: 15.8 dB

High out-of-band 3rd-order intercept point at input: +7 dBm

High 1dB-compression point: -5 dBm

Low noise figure: 0.65 dB

Low current consumption: 4.8 mA

Operating frequencies: 1550 - 1615 MHz

Supply voltage: 1.5 V to 3.6 V

Digital on/off switch (1V logic high level)

Ultra small TSLP-6-2 leadless package (footprint: 0.7 x 1.1 mm2)

B7HF Silicon Germanium technology

RF output internally matched to 50 Ω

Only 1 external SMD component necessary

2kV HBM ESD protection (including AI-pin)

Pb-free (RoHS compliant) package

Applications

 Ideal for all Global Navigation Satellite Systems (GNSS) like GPS, Galileo, GLONASS, COMPASS
