LT3493 LT3493EDCB current mode PWM step-down DC/DC converter

Features


FEATURES

Wide Input Range: 3.6V to 36V Operating,40V Maximum

1.2A Output Current

Fixed Frequency Operation: 750kHz

Output Adjustable Down to 780mV

Short-Circuit Robust

Uses Tiny Capacitors and Inductors

Soft-Start

Internally Compensated

Low Shutdown Current: <2μA

Low VCESAT Switch: 330mV at 1A

Thermally Enhanced, Low Profi le DFN Package

APPLICATIONS

Automotive Battery Regulation

Industrial Control Supplies

Wall Transformer Regulation

Distributed Supply Regulation

Battery-Powered Equipment
