AD8648 AD8648ARUZ 24 MHz Rail-to-Rail Amplifier

Features


FEATURES

Offset voltage: 2.5 mV maximum

Single-supply operation: 2.7 V to 5.5 V

Low noise: 8 nV/√Hz

Wide bandwidth: 24 MHz

Slew rate: 11 V/μs

Short-circuit output current: 120 mA

Qualified for automotive applications

No phase reversal

Low input bias current: 1 pA

Low supply current per amplifier: 2 mA maximum

Unity gain stable

APPLICATIONS

Battery-powered instruments

Multipole filters

ADC front ends

Sensors

Barcode scanners

ASIC input or output amplifiers

Audio amplifiers

Photodiode amplifiers

Datapath/mux/switch control
