ISL84051 ISL84051IBZ Low Voltage, Single and Dual Supply, 8-to-1 Multiplexer

Features


FEATURES

Drop-in Replacements for MAX4051/MAX4051A, MAX4052/MAX4052A and MAX4053/MAX4053A

Pin Compatible with MAX4581, MAX4582, MAX4583 and with Industry Standard 74HC4051, 74HC4052 and 74HC4053

ON-Resistance (rON) Max, VS = ±5V: 100Ω

ON-Resistance (rON) Max, VS = +5V: 225Ω

rON Matching Between Channels: <6Ω

Low Charge Injection: 2pC

Single Supply Operation: +2V to +12V

Dual Supply Operation: ±2V to ±6

Fast Switching Action (VS = +5V)

tON: 90ns

tOFF: 60ns

Guaranteed Max Off-leakage @ VS = ±5V: 5nA

Break-Before-Make

TTL, CMOS Compatible

Pb-Free Available (RoHS Compliant)

Target Applications:

Portable Equipment
