MAX3518 MAX3518ETP RF Amplifier DOCSIS 3.0 Upstream Amplifier

Features


FEATURES

+5V Supply Voltage

Low Power: 1.25W at 31dB Gain, 64dBmV Output

Ultra-Low 25mW Dissipation in Transmit-Disable Mode

63dB Gain Control Range in 1dB Steps

-60dBc Harmonic Distortion at 64dBmV Output

Small 5mm x 5mm Thin QFN Package

Low Burst On/Off Transient

275MHz, 3dB Bandwidth

Applications

DOCSIS 3.0 Cable Modems

VOIP Modems

Set-Top Boxes
