TPS54339 TPS54339EDDAR Switching Regulators 4.5V-23V Input 3A Synchronous Step-Down

Features


FEATURES

D-CAP2 Mode Enables Fast Transient Response

Low Output Ripple and Allows Ceramic Output Capacitor

Wide Vin Input Voltage Range:4.5V to 23V

Output Voltage Range:0.76V to 7.0V

Highly Efficient Integrated FETs Optimized

for Lower duty cycle applications

High Efficiency,less than 10uA at shutdown

High Initial Bandgap Reference Accuracy

Adjustable soft start

Pre-Biased soft start

600kHz switching Frequecy

Applications

Wide Range of Applications for Low Voltage System

Digital TV power supply

High Definition Blu-ray Disc Players

Networking Home Terminal

Digital Set top box

In Flight Display
