AD8034 AD8034ARZ Operational Amplifier Integrated Circuit

Details


FEATURES

FET input amplifier

1 pA typical input bias current

Very low cost

High speed

80 MHz, −3 dB bandwidth (G = +1)

80 V/μs slew rate (G = +2)

Low noise

11 nV/√Hz (f = 100 kHz)

0.7 fA/√Hz (f = 100 kHz)

Wide supply voltage range: 5 V to 24 V

Low offset voltage: 1 mV typical

Single-supply and rail-to-rail output

High common-mode rejection ratio: −100 dB

Low power: 3.3 mA/amplifier typical supply current

No phase reversal

Small packaging: 8-lead SOIC, 8-lead SOT-23, and 5-lead SC70
