MAX9234 MAX9234EUM IC DESERIALIZER 21BIT 48TSSOP

Details


FEATURES

♦ DC Balance Allows AC-Coupling for Wider Input Common-Mode Voltage Range

♦ On-the-Fly Frequency Programming

♦ Operating Frequency Range

8MHz to 34MHz (MAX9234/MAX9236)

16MHz to 66MHz (MAX9238)

♦ Falling-Edge Output Strobe (MAX9236/MAX9238)

♦ Slower Output Transitions for Reduced EMI(MAX9234/MAX9236)

♦ High-Impedance Outputs when PWRDWN Is Low Allow Output Busing

♦ 5V-Tolerant PWRDWN Input

♦ PLL Requires No External Components

♦ Up to 1.386Gbps Throughput

♦ Separate Output Supply Pins Allow Interface to 1.8V, 2.5V, 3.3V, and 5V Logic

♦ LVDS Inputs Meet ISO 10605 ESD Requirements

♦ LVDS Inputs Conform to ANSI TIA/EIA-644 LVDS Standard

♦ Low-Profile, 48-Lead TSSOP Package

♦ +3.3V Main Power Supply

♦ -40°C to +85°C Operating Temperature Range
