Manufacturer Part |
|
|
IC RHEOSTAT 5V 50-TP 1024 10CSP Digital Potentiometer 10k Ohm 1 Circuit 1024 Taps I²C Interface 10-LFCSP-WD (3x3) |
|
|
Mechanical rheostat replacements Op-amp: variable gain control Instrumentation: gain, offset adjustment Programmable voltage to current conversions Programmable filters, delays, time constants Programmable power supply Sensor calibration |
|
|
Datasheet |
|
Details |
|
FEATURES Single-channel, 1024-position resolution 10 kΩ nominal resistance 50-times programmable (50-TP) wiper memory Rheostat mode temperature coefficient: 35 ppm/°C 2.7 V to 5.5 V single-supply operation ±2.5 V to ±2.75 V dual-supply operation for ac or bipolar operations I2C-compatible interface Wiper setting and memory readback Power on refreshed from memory Resistor tolerance stored in memory Thin LFCSP, 10-lead, 3 mm × 3 mm × 0.8 mm package Compact MSOP, 10-lead 3 mm × 4.9 mm × 1.1 mm package |
