Manufacturer Part |
|
UC REG 1PHASE CTRLR VR12.6 20QFN Robust Ripple Regulator™ (R3) Controller, Intel VR12.6 Voltage Regulator IC 1 Output 20-QFN (3x4) |
|
Notebook computers Tablets, ultrabooks and AIO |
|
Datasheet |
Details |
FEATURES Full VR12.6 specification compliance Wide input voltage range: 4.6V to 25V R3™ control architecture delivers excellent transient response and power state mode transitions Current monitor (IMON) with temperature compensation VRHOT# indicator for CPU protection Digitally selectable switching frequency:- 425kHz, 550kHz, 700kHz with ECO and PRO options Enhanced light-load efficiency discontinuous conduction mode operation Ultra small 20 Ld 3mmx4mm QFN package Enable and power-good monitor The ISL95813 single-phase controller provides a fully compliant VR12.6 power supply solution for Intel™ microprocessors. It provides a tightly regulated output voltage that is programmed through a high speed serial bus interface with the CPU. Thisinterface also allows the CPU to acquire real-time information from the voltage regulator (VR), which includes load current and VR temperature. |
