Manufacturer Part |
|
|
16-Channel Constant Current LED Driver With 16-bit PWM Control and Dot-Correction Constant output current range per channel: 2 - 60mA Visual effect control: - Patented S-PWM technology -16-bit or 12-bit gray scale control - 8-bit dot-correction - 7-bit linear programmable output current Error detection control GFN: QFN24_4*4_0.5 |
|
|
Full-color LED display |
|
|
Datasheet |
|
Details |
|
Productgroup: S-PWM LED Driver Manufacturer: Macroblock Part Number: MBI5040GFN No. of Output Channel 16 Output Current per Channel 2-60 Sustaining Output Voltage 17 Error detection LED Open | LED Short | Thermal Protection S-PWM 12/16-bit Current Gain (12,5%-200%) 7-bit, 0%-100% Visual Refresh Rate 3840Hz@GCLK=4MHz GCLK Multiplier No Power Saving No |
