Manufacturer Part |
|
|
Clock Drivers & Distribution LVPECL/LVECL/HSTL Clock & Data Driver |
|
|
Precision Clock Distribution Low-Jitter Data Repeater Data and Clock Driver and Buffer Central Office Backplane Clock Distribution DSLAM Backplane Base Station ATE |
|
|
Datasheet |
|
Details |
|
Features +2.375V to +3.8V Supply for Differential HSTL/LVPECL Operation -2.375V to -3.8V Supply for Differential LVECL Operation Two Selectable Differential Inputs Synchronous Output Enable/Disable 20ps Output-to-Output Skew 360ps Propagation Delay Guaranteed 400mV Differential Output at 1.5GHz On-Chip Reference for Single-Ended Inputs Input Biased Low when Left Open Pin Compatible with MC100LVEP14 The MAX9315 low-skew, 1-to-5 differential driver is designed for clock and data distribution. This device allows selection between two inputs. The selected input is reproduced at five differential outputs. The differential inputs can be adapted to accept a single-ended input by connecting the on-chip VBB supply to one input as a reference voltage. |
