NCP1397 NCP1397ADR2G Switching Controller IC

Details


Product Category:Switching Controllers

Manufacturer:ON Semiconductor

RoHS:RoHS Compliant Details

Topology:Half-Bridge

Number of Outputs:2 Output

Switching Frequency:500 kHz

Duty Cycle - Max:52 %

Input Voltage:   10.5 V

Output Voltage:300 mV

Output Current:4 mA

Minimum Operating Temperature:- 40 C

Maximum Operating Temperature:+ 125 C

Mounting Style:SMD/SMT

Package / Case:SO-16

Packaging:Reel

Brand:   ON Semiconductor

Description/Function:     High performance resonant mode controller with integrated high-voltage drivers

Fall Time:20 ns

Isolation:Non-Isolated

Operating Supply Current:4 mA

Operating Supply Voltage:20 V

Product:Resonant Mode Controllers

Rise Time:40 ns

Series:  NCP1397

Shutdown:Shutdown

Factory Pack Quantity:2500

Type:Current Mode PWM Controller

Unit Weight:0.007079 oz

The NCP1397 is a high performance controller that can be utilized in half bridge resonant topologies such as series resonant, parallel resonant and LLC resonant converters.
