SE2577L SE2577L-R Dual-Band 802.11n Wireless LAN Front-End Module

Manufacturer	Skyworks
Manufacturer Part	SE2577L-R
Description	RF IC Front End 802.11a/g/n 2.4GHz
Application	802.11n, MIMO solutions IEEE 802.11g OFDM WLAN IEEE 802.11a OFDM WLAN Access points, PCMCIA, PC cards
Datasheet	SE2577L

Details


Features

Passive front end, including two SPDT switches and diplexer

Integrated 2 GHz low pass filter

Able to accept 20 dBm of linear input power in both bands with no EVM contribution

Lead free, Halogen Free and RoHS compliant

Thin lead-free plated QFN package (20-pin, 3 x 3 x 0.9 mm,(MSL1, 260 °C per JEDEC J-STD-020)
