Manufacturer Part |
|
|
Switching Controllers 70A Synchronous Buck NexFET Smart Power Stage in an Industry Standard Footprint 41-VQFN-CLIP -55 to 150 |
|
|
• Multiphase Synchronous Buck Converters – High-Frequency Applications – High-Current, Low-Duty Cycle Applications • POL DC-DC Converters • Memory and Graphic Cards • Desktop and Server VR12.x / VR13.x V-Core Synchronous Buck Converters |
|
|
Datasheet |
|
Details |
|
Features • 70-A Continuous Operating Current Capability • Over 95% System Efficiency at 30 A • High-Frequency Operation (up to 1.25 MHz) • Diode Emulation Function • Temperature Compensated Bi-Directional Current Sense • Analog Temperature Output • Fault Monitoring • 3.3-V and 5-V PWM Signal Compatible • Tri-State PWM Input • Integrated Bootstrap Switch • Optimized Dead Time for Shoot-Through Protection • High-Density QFN 5-mm × 6-mm Footprint • Ultra-Low-Inductance Package • System Optimized PCB Footprint • Thermally Enhanced Topside Cooling • RoHS Compliant – Lead-Free Terminal Plating • Halogen Free |
