TPS73533DRBR TPS735 Voltage Regulator IC

Details


Manufacturer: Texas Instruments

Product Category: LDO Voltage Regulators

Mounting Style: SMD/SMT

Package / Case: VSON-8

Output Voltage: 3.3 V

Output Current: 500 mA

Number of Outputs: 1 Output

Polarity: Positive

Input Voltage MAX: 6.5 V

Input Voltage MIN: 2.7 V

Output Type: Fixed

Minimum Operating Temperature: - 40 C

Maximum Operating Temperature: + 125 C

Load Regulation: 0.005 %/mA

Series: TPS73533

Dropout Voltage: 280 mV

Packaging: Cut Tape

Packaging: MouseReel

Packaging: Reel

Height: 0.88 mm

Length: 3 mm

Operating Temperature Range: - 40 C to + 125 C

Width: 3 mm

Brand: Texas Instruments

Dropout Voltage - Max: 500 mV at 500 mA

Voltage Regulation Accuracy: 1 %

Ib - Input Bias Current: 46 uA

Line Regulation: 0.02 % / V

Operating Supply Current: 45 uA

Pd - Power Dissipation: 2.5 W

Product Type: LDO Voltage Regulators

Factory Pack Quantity: 3000

Subcategory: PMIC - Power Management ICs

The TPS735 device is stable with ceramic capacitors and uses an advanced BiCMOS fabrication process to yield a typical dropout voltage of 280 mV at 500-mA output. The TPS735 device uses a precision voltage reference and feedback loop to achieve overall accuracy of 2% (VOUT > 2.2 V) over all load, line, process, and temperature variations.
