Manufacturer Part |
|
|
Isolation Amplifiers Automotive Precision, +/-250mV Input, 3us Delay, Reinforced Isolated Amplifier 8-SOIC -40 to 125 |
|
|
Shunt-Based Current Sensing or Resistor-Divider Based Voltage Sensing In: Traction Inverters Onboard Chargers (OBC) DC-DC Converters Battery Management Systems (BMS) |
|
|
Datasheet |
|
Details |
|
Manufacturer: Texas Instruments Product Category: Isolation Amplifiers Series: AMC1301-Q1 Number of Channels: 2 Channel Isolation Voltage: 5000 Vrms Isolation Type: Galvanic GBP - Gain Bandwidth Product: 1000 kHz 3 dB Bandwidth: - CMRR - Common Mode Rejection Ratio: 92 dB Ib - Input Bias Current: - 60uA Vos - Input Offset Voltage: 50uV Supply Voltage - Max: 5.5 V Supply Voltage - Min: 3 V Operating Supply Current: 5.9mA Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 125 C Mounting Style: SMD/SMT Package / Case: SOIC-Wide-8 Qualification: AEC-Q100 Packaging: Cut Tape Packaging: Mouse Reel Packaging: Reel Amplifier Type: Precision Isolated Amplifier Input Type: Differential, Single-Ended Product: Isolation Amplifiers Brand: Texas Instruments Shutdown: No Shutdown Development Kit: AMC1301EVM Gain Error: 0.03 % Output Current per Channel: 13 mA Pd - Power Dissipation: 81.4 mW Product Type: Isolation Amplifiers PSRR - Power Supply Rejection Ratio: - 90 dB SR - Slew Rate: - Factory Pack Quantity: 1000 Subcategory: Amplifier ICs The AMC1301-Q1 device is a precision, isolated amplifier with an output separated from the input circuitry by an isolation barrier that is highly resistant to magnetic interference. |
