Manufacturer Part |
|
Microwave Coaxial Connectors |
|
Cellular phone, Wearable equipment and other wireless equipment |
|
Datasheet |
Details |
Image Features 1. The microwave coaxial connector with cables is small, thin and suitable for internal wiring of cellular phone and small wireless equipment such as wearable equipment. 2. Receptacle size 1.7x1.6 (LxW), Occupation area 2.72mm2 3. Mating height is 0.8mm max., which is world lowest profile level, with cable and receptacle. 4. Diameter of receptacle cylinder is equal size with JSC type connector. It makes easy to mate cable and connector. 5. V.S.W.R. 1.4 max. (DC to 6GHz) 6. This has good lock feeling when cable and receptacle are mated. 7. Nominal Impedance: 50Ω 8. Rated Voltage: 30Vrms 9. Temperature Rating: -40 to 85°C. |
