High resolution display microcontroller I-CHIPS IP00C732

客户Manufacturer

I-CHIPS

Manufacturer Part

IP00C732

Description

High resolution display microcontroller

Application

 Flat-Panel Displays

 Projection Systems

 Video Walls

LCD/TV Monitors

 Plasma Displays

Datasheet

IP00C732

Details


Image input (4 systems)

     RGB 30bit/YUV4:4:4 30bit/ YUV4:2:2 20bit 166MHz

     Support progressive/interlaced

Image output (4 systems)

     RGB 30bit/YUV4:4:4 30bit/ YUV4:2:2 20bit 166MHz

     Support progressive/interlaced

External image memory

     DDR2-SDRAM 64bit

Zoom in and out

     Equipped with 4 zooming and zooming engines

     6-stage filter

     Vertical and horizontal independent magnification settings, and panoramic conversion

Bitmap OSD

     Support 256 colors

     Font data expansion function (65536 characters)

     Through color 4 color, flashing function

     4ch output ports can work independently

     Ability to transfer bitmaps from serial flash memory

Image correction function

     4ch superposition, alpha fusion

    Chroma key correction

     Flip up and down

     90° rotation (1ch)

Picture quality adjustment function

     Equipped with 3x3 color conversion matrix, bias

CPU interface

    8bit parallel/4-wire series/I2C

other

     3.3V/1.8V/1.2V 3 power supplies

     544 pin BGA

     Molded part 27mm angle, ball pitch 1.00mm
