Manufacturer Part |
||
|
Ethernet ICs SINGLE GBE SERDES PHY |
||
|
The BCM5461S is a fully integrated 10/100/1000BASE-T Gigabit Ethernet transceiver optimized for low power and small footprint size to enable backplane and uplink applications. |
||
|
Datasheet |
||
|
Details |
||
|
Image Fully-integrated 10BASE-T/100BASE-TX/1000BASE-T Gigabit Ethernet transceiver GMII, RGMII, SGMII, SerDes, RTBI and MII MAC Interface options Line-side copper and fiber interfaces On-chip low-voltage regulators Fully compliant with IEEE 802.3, 802.3u, and 802.3ab standards 0.13µ CMOS — low power and cost Low power Less than 700 mW per port Wake on LAN support Advanced power management Trace matched output impedance Line-side loopback Low EMI emissions Cable plant diagnostic Cable plant analyzer function detects cable plant impairments Link quality indication LED Automatic detection and correction of wiring pair swaps, pair skew, and pair polarity Automatic MDI/MDIX crossover at all speeds Robust CESD tolerance Support for jumbo packets up to 9 KB IEEE 1149.1 (JTAG) boundary scan 128-pin MQFP, 117-pin BGA, and 100-pin FBGA packages
method of payment Telegraphic Exchange (T / T) 2.PayPal 3.Western Union If you are interested in our products, please contact Jane.Lu@szmjd.net List other products: up to http://www.mjdic.com/ |
||
