Nexperia《2N7002BKW》MOSFET Single N-Channel 60V 300mA

Manufacturer

Nexperia

Manufacturer Part

2N7002BKW

Description

MOSFET Single N-Channel 60V 300mA

Application

Relay driver

High-speed line driver

Low-side loadswitch

Switching circuits

Datasheet

2N7002

Details


Product Category:MOSFET

RoHS: Details

Technology:Si

Mounting Style:SMD/SMT

Package / Case:SOT-323-3

Number of Channels:1 Channel

Transistor Polarity:N-Channel

Vds - Drain-Source Breakdown Voltage:60 V

Id - Continuous Drain Current:310 mA

Rds On - Drain-Source Resistance:1.6 Ohms

Vgs - Gate-Source Voltage:10 V

Vgs th - Gate-Source Threshold Voltage:1.1 V

Qg - Gate Charge:0.5 nC

Minimum Operating Temperature:- 55 C

Maximum Operating Temperature:+ 150 C

Pd - Power Dissipation:330 mW (1/3 W)

Configuration:Single

Channel Mode:Enhancement

Qualification:AEC-Q101

Packaging:Cut Tape

Packaging:MouseReel

Packaging:Reel

Product:MOSFET Small Signal

Transistor Type:1 N-Channel Trench MOSFET

Type:Enhancement

Brand:Nexperia

Fall Time:7 ns

Product Type:MOSFET

Rise Time:6 ns

Factory Pack Quantity:3000

Subcategory:MOSFETs

Typical Turn-Off Delay Time:12 ns

Typical Turn-On Delay Time:5 ns

Unit Weight:0.000176 oz

PN：2N7002BKW
