Analog Devices《ADUM1210BRZ》Digital Isolators DUAL-CHANNEL DIGITAL ISOLATORS

Manufacturer

Analog Devices

Manufacturer Part

ADUM1210BRZ

Description

Digital Isolators DUAL-CHANNEL DIGITAL ISOLATORS

Application

Size-critical multichannel isolation

SPI interface/data converter isolation

RS-232/RS-422/RS-485 transceiver isolation

Digital field bus isolation

Gate drive interface

Datasheet

ADUM1210

Details


Product Category:Digital Isolators

RoHS: Details

Mounting Style:SMD/SMT

Package / Case:SOIC-8

Series:ADUM1210

Number of Channels:2 Channel

Polarity:Unidirectional

Isolation Voltage:2.5 kVrms

Isolation Type:Magnetic Coupling

Data Rate:10 Mb/s

Propagation Delay Time:50 ns

Supply Voltage - Max:5.5 V

Supply Voltage - Min:2.7 V

Operating Supply Current:600 uA

Minimum Operating Temperature:- 40 C

Maximum Operating Temperature:+ 105 C

Packaging:Tube

Product:Digital Isolators

Type:General Purpose

Brand:Analog Devices

Maximum Fall Time:3 ns (Typ)

Maximum Rise Time:3 ns (Typ)

Operating Supply Voltage:5.5 V

Product Type:Digital Isolators

Pulse Width:100 ns

Factory Pack Quantity:98

Subcategory:Interface ICs

Unit Weight:0.019048 oz

Part # Aliases:ADUM1210BRZ
