INFINEON《BSC090N03LSG》MOSFET N-Ch 30V 47A TDSON-8 OptiMOS 3

Manufacturer

Infineon Technologies

Manufacturer Part

BSC090N03LSG

Description

MOSFET N-Ch 30V 47A TDSON-8 OptiMOS 3

Application

Fast switching MOSFET for SMPS

Optimized technology for DC/DC converters

Qualified according to JEDEC1) for target applications

N-channel; Logic level

Datasheet

BSC090

Details


Product Category:MOSFET

RoHS: Details

Technology:Si

Mounting Style:SMD/SMT

Package / Case:TDSON-8

Transistor Polarity:N-Channel

Number of Channels:1 Channel

Vds - Drain-Source Breakdown Voltage:30 V

Id - Continuous Drain Current:48 A

Rds On - Drain-Source Resistance:7.5 mOhms

Vgs - Gate-Source Voltage:20 V

Vgs th - Gate-Source Threshold Voltage:1 V

Qg - Gate Charge:18 nC

Minimum Operating Temperature:- 55 C

Maximum Operating Temperature:+ 150 C

Pd - Power Dissipation:32 W

Channel Mode:Enhancement

Tradename:OptiMOS

Packaging:Cut Tape

Packaging:MouseReel

Packaging:Reel

Configuration:Single

Height:1.27 mm

Length:5.9 mm

Series:OptiMOS 3

Transistor Type:1 N-Channel

Width:5.15 mm

Brand:Infineon Technologies

Forward Transconductance - Min:28 S

Fall Time:2.4 ns

Product Type:MOSFET

Rise Time:2.6 ns

Factory Pack Quantity:5000

Subcategory:MOSFETs

Typical Turn-Off Delay Time:14 ns

Typical Turn-On Delay Time:3.1 ns

Unit Weight:0.004358 oz

Part # Aliases:BSC090N03LSG
