Infineon《IPA60R380P6》MOSFET N-Ch 600V 6.5A TO220FP-3

Manufacturer

Infineon Technologies

Manufacturer Part

IPA60R380P6

Description

MOSFET N-Ch 600V 6.5A TO220FP-3

Application

PFCstages,hard switching PWM stages and resonant switching  stages for e.g.PC Silverbox

Datasheet

IPA60R380P6

Details


Product Category:MOSFET

RoHS: Details

Technology:Si

Mounting Style:Through Hole

Package / Case:TO-220-3

Transistor Polarity:N-Channel

Number of Channels:1 Channel

Vds - Drain-Source Breakdown Voltage:600 V

Id - Continuous Drain Current:10.6 A

Rds On - Drain-Source Resistance:342 mOhms

Vgs - Gate-Source Voltage:20 V

Vgs th - Gate-Source Threshold Voltage:3.5 V

Qg - Gate Charge:19 nC

Minimum Operating Temperature:- 55 C

Maximum Operating Temperature:+ 150 C

Pd - Power Dissipation:31 W

Channel Mode:Enhancement

Tradename:CoolMOS

Packaging:Tube

Configuration:Single

Height:16.15 mm

Length:10.65 mm

Series:CoolMOS P6

Transistor Type:1 N-Channel

Width:4.85 mm

Brand:Infineon Technologies

Fall Time:7 ns

Product Type:MOSFET

Rise Time:6 ns

Factory Pack Quantity:500

Subcategory:MOSFETs

Typical Turn-Off Delay Time:33 ns

Typical Turn-On Delay Time:12 ns

Unit Weight:0.211644 oz

Part # Aliases:IPA60R380P6
