Single Cell Li-Ion/Polymer Battery BQ25606RGER BQ25606 Charger IC

Model: BQ25606RGER

D/C: 21+

Package: VQFN24


The BQ25606 single-cell 3A fast charger is a stand-alone switch-mode battery charge management and system power path management device. The device is suitable for single-cell Li-Ion and Li-polymer batteries. The low-impedance power path optimizes switch-mode operation efficiency, reducing battery charging time and extending battery life during the discharge phase.



Fast charging with high input voltage, suitable for a variety of standalone chargers and portable devices. Input voltage and current regulation provides maximum charging power for the battery. The solution highly integrates the input reverse blocking FET (RBFET, Q1), high-side switching FET (HSFET, Q2), low-side switching FET (LSFET, Q3) and battery FET (BATFET, Q4) between system and battery . The device also integrates a bootstrap diode for the high-side gate driver to simplify system design.



Specification

Battery Chemistry Li-Ion/Polymer

Number of batteries 1

Current - Charge Constant Current - Programmable

Programmable Features -

Fault protection over temperature, over voltage, short circuit

Charge Current - 3A max

Battery pack voltage 4.4V

Voltage - Supply (Max) 13.5V

Interface USB

Operating temperature -40°C ~ 85°C (TA)

Mounting Type Surface Mount

Package/Case 24-VFQFN Exposed Pad

Vendor Device Package 24-VQFN (4x4)
