The VNS1NV04DP is comprised of two monolithic OMNIFET II chips packaged in a standard SO-8 package. OMNIFET II are designed using STMicroelectronics VIPower™ M0-3 technology: they are designed to replace standard power MOSFET applications from DC to 50KHz. Built-in thermal shutdown, linear current limit and overvoltage clamp protect the chip in harsh environments. Fault feedback can be monitored to detect the voltage on the input pins.
Model: VNS1NV04DPTR
Brand: ST
Lot number: 1836+
Package: SOP
Specifications
Switch Type Universal
Number of outputs 2
Ratio - Input:Output 1:1
Output Configuration Low Side
Output type N channel
Interface On/Off
Voltage - Load 36V (max)
Voltage - Supply (Vcc/Vdd) Not required
Current - Output (Max) 1.7A
On-resistance (typ) 250 milliohms (max)
Input Type Non-inverting
Features -
Fault Protection Current Limit (Fixed), Over Temperature, Over Voltage
Operating temperature -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package 8-SOIC
Package/Case 8-SOIC (0.154", 3.90mm wide)
