Shenzhen Mingjiada Electronics supply transistor IRF3808STRLPBF MOSFET N-CH 75V 106A D2PAK, new and original, welcome to consult!
Model: IRF3808STRLPBF
Batch number: 11+
Package: TO-263
Product Specification
FET Type N-channel
Technology MOSFET (metal oxide)
Current at 25°C - continuous drain (Id) 106A (Tc)
Drive voltage (max Rds On, min Rds On) 10V
On-resistance at different Id, Vgs (max) 7 milliohms @ 82A, 10V
Vgs(th) at different Id (max) 4V @ 250µA
Vgs (max) ±20V
FET function -
Power dissipation (max) 200W (Tc)
Operating Temperature -55°C ~ 175°C (TJ)
Mounting Type Surface Mount Type
Supplier Device Package D2PAK
Package/Case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Drain source voltage (Vdss) 75 V
Gate charge (Qg) at different Vgs (max) 220 nC @ 10 V
Input capacitance (Ciss) at different Vds (max) 5310 pF @ 25 V
